Ubiquiti Switch Enterprise 8-port PoE+ 8x2.5GbE, Ideal For Wi-Fi 6 AP, 2x 10g SFP+ Ports For Uplinks, Managed Layer 3 Switch
SKU: 124610
Ubiquiti Switch Enterprise 8-port PoE+ 8x2.5GbE, Ideal For Wi-Fi 6 AP, 2x 10g SFP+ Ports For Uplinks, Managed Layer 3 Switch
SKU: 124610
Layer 3, PoE switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.
The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) 1.3" LCM color touchscreen with AR switch management
(8) 2.5GbE, 802.3at PoE+ RJ45 ports
(2) 10G SFP+ ports
120W total PoE supply
Wall-mountable (kit included)
* Layer 3 switching will become available in a future firmware update.
Managed with the UniFi Network application: Version 6.3.51 and later
(124610)
| Mechanical | |
|---|---|
| Dimensions | 200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
| Weight | 2.4 kg (5.29 lb) |
| Enclosure material | Polycarbonate |
| Mount material | Polycarbonate |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) 2.5 GbE, PoE+ RJ45 ports (2) 10G SFP+ |
| PoE interface | (8) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Total non-blocking throughput | 40 Gbps |
| Switching capacity | 80 Gbps |
| Forwarding rate | 59.52 Mpps |
| Power method | (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz |
| Power supply | AC/DC, internal, 150W |
| Supported voltage range | 100—240V AC |
| Max PoE power | 120W |
| Max. PoE+ wattage per port by PSE | 32W |
| Voltage range PoE mode | PoE: 44—57V PoE+: 50—57V |
| LCM Display | (1) 1.3" color touchscreen |
| Mounting | Desktop-mountable (Do not physically stack the USW-Enterprise-8-PoE.) |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Operating temperature | -5 to 45° C (23 to 113° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | Link/activity |
| SFP+ | Link/activity |
| Application Requirements | |
| UniFi Network | Version 6.3.51 and later |
| SKU | 124610 |
| Barcode # | 810010074874 |
| Brand | UBIQUITI |
| Shipping Weight | 2.7400kg |
| Shipping Width | 0.260m |
| Shipping Height | 0.080m |
| Shipping Length | 0.370m |
Be The First To Review This Product!
Help other OnLine Centre Pty Ltd users shop smarter by writing reviews for products you have purchased.
Layer 3, PoE switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.
The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) 1.3" LCM color touchscreen with AR switch management
(8) 2.5GbE, 802.3at PoE+ RJ45 ports
(2) 10G SFP+ ports
120W total PoE supply
Wall-mountable (kit included)
* Layer 3 switching will become available in a future firmware update.
Managed with the UniFi Network application: Version 6.3.51 and later
| Mechanical | |
|---|---|
| Dimensions | 200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
| Weight | 2.4 kg (5.29 lb) |
| Enclosure material | Polycarbonate |
| Mount material | Polycarbonate |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) 2.5 GbE, PoE+ RJ45 ports (2) 10G SFP+ |
| PoE interface | (8) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Total non-blocking throughput | 40 Gbps |
| Switching capacity | 80 Gbps |
| Forwarding rate | 59.52 Mpps |
| Power method | (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz |
| Power supply | AC/DC, internal, 150W |
| Supported voltage range | 100—240V AC |
| Max PoE power | 120W |
| Max. PoE+ wattage per port by PSE | 32W |
| Voltage range PoE mode | PoE: 44—57V PoE+: 50—57V |
| LCM Display | (1) 1.3" color touchscreen |
| Mounting | Desktop-mountable (Do not physically stack the USW-Enterprise-8-PoE.) |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Operating temperature | -5 to 45° C (23 to 113° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | Link/activity |
| SFP+ | Link/activity |
| Application Requirements | |
| UniFi Network | Version 6.3.51 and later |
| SKU | 124610 |
| Barcode # | 810010074874 |
| Brand | UBIQUITI |
