Ubiquiti UniFi Wi-Fi 6 Long-Range AP 4x4 Mu-/Mimo Wi-Fi 6, 2.4GHz @ 600Mbps & 5GHz @ 2.4Gbps **No POE Injector Included**

SKU: 124580

Maximize your network's WiFi coverage and roaming performance.

Features:
- 2,000 ft² coverage
- 350+ connected devices
- WiFi6 (4x4 MIMO)
- Powered using PoE+

(124580)

Mechanical
Dimensions Ø220 x 48 mm (Ø8.66 x 1.89")
Weight Without mount: 800 g (1.76 lb)
With mount: 930 g (2.05 lb)
Enclosure material Polycarbonate
Mount material Stainless steel (SUS304)
Weatherproofing IP54
Hardware
Networking interface (1) GbE RJ45 port
Management interface Ethernet
Bluetooth
Power method PoE+, passive PoE (48V)
Power supply UniFi PoE switch
48V, 0.5A PoE adapter (Not included)
Supported voltage range 44—57V DC
Max. power consumption 18.5W
Max. TX power
2.4 GHz
5 GHz
26 dBm
26 dBm
MIMO
2.4 GHz
5 GHz
4 x 4
4 x 4
Throughput rate
2.4 GHz
5 GHz
600 Mbps
2400 Mbps
Antenna gain
2.4 GHz
5 GHz
4 dBi
5.5 dBi
LEDs White/blue
Button Factory reset
Mounting Wall/ceiling (Included)
Operating temperature -30 to 60° C (-22 to 140° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 350+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
Application Requirements
UniFi Network Version 6.0.34 and later
SKU 124580
Barcode # 810010073389
Brand UBIQUITI
Shipping Weight 1.6800kg
Shipping Width 0.260m
Shipping Height 0.080m
Shipping Length 0.260m
