Ubiquiti UniFi Switch Flex XG - Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE, 802.3at PoE+ RJ45 input.
SKU: 124612
Ubiquiti UniFi Switch Flex XG - Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE, 802.3at PoE+ RJ45 input.
SKU: 124612
The Switch Flex XG (USW Flex XG) is a fully managed, mult-gigabit, Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input. The USW Flex XG sports slim, compact housing and can be mounted on a desktop*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) GbE, 802.3at PoE+ RJ45 input
(4) 10GbE RJ45 ports
Compact, slim housing
Can be powered with a 5V, 5A USB-C adapter
*Fanless Switch, Do not stack other hardware on the USW Flex XG, will affect heat dissipation
(124612)
| Mechanical | |
|---|---|
| Dimensions | 135 x 185 x 32 mm (5.3 x 7.3 x 1.3") |
| Weight | 1.2 kg (2.6 lb) |
| Enclosure material | Polycarbonate |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (1) GbE, PoE+ RJ45 port (4) 10 GbE RJ45 ports |
| Total non-blocking throughput | 41 Gbps |
| Switching capacity | 82 Gbps |
| Forwarding rate | 61.012 Mpps |
| Power method | (1) PoE+, 50—57V DC, 25W (1) USB Type-C, 5V DC, 5A |
| Power supply | PoE+ (Pins 1, 2+/3, 6- or 4, 5+/7, 8-) AC/DC power adapter, 5V DC, 5A, 1.5 m cord (Included) |
| Supported voltage range | 90—264V AC (Adapter) |
| Max. power consumption | 25W |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Button | Factory reset |
| Operating temperature | -5 to 45° C (23 to 113° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | Speed/link/activity |
| Application Requirements | |
| UniFi Network | Version 6.1.67 and later |
| SKU | 124612 |
| Barcode # | 810010075895 |
| Brand | UBIQUITI |
| Shipping Weight | 1.6000kg |
| Shipping Width | 0.180m |
| Shipping Height | 0.070m |
| Shipping Length | 0.290m |
Be The First To Review This Product!
Help other OnLine Centre Pty Ltd users shop smarter by writing reviews for products you have purchased.
The Switch Flex XG (USW Flex XG) is a fully managed, mult-gigabit, Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input. The USW Flex XG sports slim, compact housing and can be mounted on a desktop*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) GbE, 802.3at PoE+ RJ45 input
(4) 10GbE RJ45 ports
Compact, slim housing
Can be powered with a 5V, 5A USB-C adapter
*Fanless Switch, Do not stack other hardware on the USW Flex XG, will affect heat dissipation
| Mechanical | |
|---|---|
| Dimensions | 135 x 185 x 32 mm (5.3 x 7.3 x 1.3") |
| Weight | 1.2 kg (2.6 lb) |
| Enclosure material | Polycarbonate |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (1) GbE, PoE+ RJ45 port (4) 10 GbE RJ45 ports |
| Total non-blocking throughput | 41 Gbps |
| Switching capacity | 82 Gbps |
| Forwarding rate | 61.012 Mpps |
| Power method | (1) PoE+, 50—57V DC, 25W (1) USB Type-C, 5V DC, 5A |
| Power supply | PoE+ (Pins 1, 2+/3, 6- or 4, 5+/7, 8-) AC/DC power adapter, 5V DC, 5A, 1.5 m cord (Included) |
| Supported voltage range | 90—264V AC (Adapter) |
| Max. power consumption | 25W |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Button | Factory reset |
| Operating temperature | -5 to 45° C (23 to 113° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | Speed/link/activity |
| Application Requirements | |
| UniFi Network | Version 6.1.67 and later |
| SKU | 124612 |
| Barcode # | 810010075895 |
| Brand | UBIQUITI |
