Ubiquiti UniFi Wi-Fi 6 In-Wall Wall-mounted Access Point with a built-in PoE switch.

MechanicalDimensions139.66 x 96 x 31.19 mm (5.5 x 3.78 x 1.28")Weight460 g (1.01 lb)Enclosure materialsPlastic, aluminumMount materialAluminumHardwareNetworking interface(1) Data-in: 1GbE RJ45 port
(4) Data-out: 1GbE RJ45 portsManagement interfaceEthernet
BluetoothPoE interface(1) PoE in (PoE output not used)
(1) PoE out (Requires a PoE+ switch)Power methodPoEPower supplyUniFi PoE switch
48V, 0.5A PoE adapter (Optional)Max. power consumptionExcluding PoE output: 13.5WMax PoE wattage per port by PSE15.4W*
*Requires a PoE+ switchVoltage range PoE mode44—57V DCMax. TX power
2.4 GHz
5 GHz
22 dBm
26 dBmMIMO
2.4 GHz
5 GHz
2 x 2 (UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)Throughput rate
2.4 GHz
5 GHz
573.5 Mbps
4.8 GbpsAntenna gain
2.4 GHz
5 GHz
5 dBi
5.9 dBiLEDWhite/blueButtonFactory resetOperating temperature-30 to 60° C (-22 to 140° F)Operating humidity5 to 95% noncondensingCertificationsCE, FCC, ICSoftwareWiFi standards802.11a/b/g
WiFi 4/WiFi 5/WiFi 6Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)BSSID8 per radioVLAN802.1QAdvanced QoSPer-user rate limitingGuest traffic isolationSupportedConcurrent clients300+Zero-wait DFSYes*
*Supported with upcoming firmware versions.Supported Data Rates802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps802.11b1, 2, 5.5, 11 Mbps802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)Application RequirementsUniFi NetworkVersion 6.4.52 and later
