Ubiquiti Unifi Wi-Fi 6 Mesh AP 4x4 Mu-/Mimo Wi-Fi 6, 2.4Ghz @ 573.5Mbps & 5GHz @ 4.8Gbps, PoE Injector Included

SKU: 124584

Ubiquiti Unifi Wi-Fi 6 Mesh AP 4x4 Mu-/Mimo Wi-Fi 6, 2.4Ghz @ 573.5Mbps & 5GHz @ 4.8Gbps, PoE Injector Included

Indoor/outdoor, 4x4 WiFi 6 access point designed for mesh applications.


The UniFi6 Mesh (U6 Mesh) is a high-performance, four-stream WiFi 6 access point that provides best-in-class signal meshing to enhance the wireless coverage of home and enterprise networks. The U6 Mesh can reach an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz (2x2 MU-MIMO and OFDMA) bands. This access point also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. The sleek U6 Mesh is discreet enough to stage anywhere in your home or office, but also rugged enough to reliably operate outdoors thanks to its IPX5-rated, waterproof housing. The U6 Mesh is a plug-and-play device designed to easily extend your wireless signal to ensure full, seamless coverage and high-quality WiFi connectivity. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.


Features

• High-efficiency 4x4 WiFi 6 (802.11ax)

• 5 GHz (4x4 MU-MIMO and OFDMA) band with a 4.8 Gbps throughput rate

• 2.4 GHz (2x2 MU-MIMO and OFDMA) band with a 573.5 throughput rate

• Operates at full 4x4 MIMO with 160 MHz bandwidth

• Powered with PoE (PoE adapter included)

(124584)

Mechanical
Dimensions Ø48.5 x 159.5 mm (Ø1.9 x 6.28")
Weight 400 g (0.88 lb)
Enclosure material Plastic, aluminum
Mount materials Plastic
Weatherproofing IPX5
Hardware
Networking interface (1) GbE RJ45 port
Management interfaces Ethernet
Bluetooth
Power method PoE
Power supply UniFi PoE switch
48V, 0.32A PoE adapter (included)
Supported voltage range 44—57V DC
Max. power consumption 11.4W
Max. TX power
2.4 GHz
5 GHz

22 dBm
26 dBm
MIMO
2.4 GHz
5 GHz

2 x 2 (UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz

573.5 Mbps
4.8 Gbps
Antenna gain
2.4 GHz
5 GHz

3 dBi
5 dBi
LEDs White/blue
Button Factory reset
Mounting Wall, desktop, pole mount (Included)
Ceiling mount (Optional)
Operating temperature -30 to 60° C (-22 to 140° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Zero wait DFS Yes*
*Supported with upcoming firmware versions
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
Application Requirements
UniFi Network Version 6.2.51 and later
SKU 124584
Barcode # 810010078025
Brand UBIQUITI
Shipping Weight 1.1000kg
Shipping Width 0.120m
Shipping Height 0.090m
Shipping Length 0.180m
