TP-Link TL-MCRP100 100-240V Redundant Power Supply Module

SKU: 123156

The TP-LINK Redundant Power Supply Module TL-MCRP100 is an AC-input and DC-output power supply module. It can convert 100-240V 50/60Hz input voltage into 12VDC output with rated wattage of 102W. The power supply module supports output over-voltage/short circuit/over-current protection. TL-MCRP100 is applicable to 14-Slot Rackmount Chassis TL-MC1400.

* TL-MCRP100 v2.0 supports TL-MC1400 v3.0, TL-MCRP100 v1.0 supports TL-MC1400 v1.0/2.0.

Fan Quantity 1
REDUNDANT POWER SUPPLY
AC Power Input 100-240V~ 50/60Hz 3A
DC Power Output 12V/8.5A
Dimensions 193.4*162.3*42.2 mm
Environment Operating Temperature: 0℃~60℃ (32℉~140℉)
Storage Temperature: -35℃~85℃ (-31℉~185℉)
Operating Humidity: 20%~90%RH non-condensing
Storage Humidity: 10%~95%RH non-condensing
OTHERS
Warranty Limited 3-Year Warranty

For further information on our warranty policy please visit: http://www.tp-link.com.au/support/rma

(123156)

SKU 123156
Model # TL-MCRP100
Barcode # 6935364099848
Brand TP-LINK
Shipping Width 0.100m
Shipping Height 0.100m
Shipping Length 0.100m
