Lenovo ThinkCentre Neo 50q G5 13B9005EAU Core i5-13420H 16GB 512GB SSD W11P 1YOS

SKU: 127889

PERFORMANCE
Processor
Intel Core™ i5-13420H, 8C (4P + 4E) / 12T, P-core up to 4.6GHz, E-core up to 3.4GHz, 12MB Intel® Smart Cache
Graphics
Integrated Intel® UHD Graphics
Chipset
Intel® SoC Platform
Memory
2x 8GB SODIMM DDR5-5600
Memory Slots
Two DDR5 SODIMM slots, dual-channel capable
Max Memory

Up to 64GB DDR5-5600
Storage
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
Max Storage Support

Up to two drives, 2x M.2 SSD • M.2 SSD up to 1TB each
RAID Preset
None
Card Reader
No card reader
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC256 codec
Speakers
2Wx1
Camera
No camera
Microphone
No microphone
Power Supply

90W 89% Adapter
DESIGN
Keyboard
USB, Calliope, Black, English (US)
Mouse
USB Calliope Mouse, Black
Optional Bay
None
Expansion Slots
Three M.2 slots (one for WLAN, two for SSD)
Case Color
Black
Stand
None
Adapter Cage
None
Toolless Chassis Screw
None
Mounting
None
IO Box
No IO box
Pen
Pen Not Supported
Form Factor
Tiny (1L)
Dimensions (WxDxH)

Tiny only (without rubber feet) | 179 x 182.9 x 34.5 mm (7.05 x 7.2 x 1.36 inches)
Tiny only (with rubber feet) | 179 x 182.9 x 36.5 mm (7.05 x 7.2 x 1.44 inches)
Weight

Around 1.13 kg (2.49 lbs)
CONNECTIVITY
WLAN + Bluetooth
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3
WWAN
WWAN Not Supported
Ethernet
Integrated 100/1000M
Front Ports
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 5V@3A charging
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging
1x headphone / microphone combo jack (3.5mm)
Rear Ports
2x USB-A (Hi-Speed USB / USB 2.0), one supports Smart Power On
2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x HDMI® 2.1 TMDS
1x DisplayPort™ 1.4b
1x Ethernet (GbE RJ-45)
1x Power connector
Optional Rear Ports (configured)
DP 1.4
Monitor Cable
None
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Fingerprint Reader
No fingerprint reader
Physical Locks
Kensington Security Slot™, 3 x 7 mm
Chassis Intrusion Switch
Chassis Intrusion Switch

MANAGEABILITY
System Management
Non-vPro®
SERVICE
Base Warranty
1-year, Onsite
Included Upgrade
None

(127889)

SKU 127889
Model # 13B9005EAU
Barcode # 199272548324
Brand LENOVO
Shipping Weight 3.0600kg
Shipping Width 0.250m
Shipping Height 0.130m
Shipping Length 0.490m
