FWF-60F-N

SKU: 124566

With a rich set of AI/ML-based FortiGuard security services and our integrated Security Fabric platform, the FortiGate FortiWiFi 60F series delivers coordinated, automated, end-to-end threat protection across all use cases.

FortiGate has the industry’s first integrated SD-WAN and zero-trust network access (ZTNA) enforcement within an NGFW solution and is powered by one OS. FortiGate FortiWiFi 60F automatically controls, verifies, and facilitates user access to applications, delivering consistency with a seamless and optimized user experience.

(124566)

Specifications:

	FortiGate 60F/FortiWifi 60F	FortiGate 61F/FortiWifi 61F
Hardware Specifications
GE RJ45 WAN / DMZ Ports	2/1
GE RJ45 Internal Ports	7
GE RJ45 FortiLink Ports	2
GE RJ45 PoE/+ Ports	-
Wireless Interface	802.11 a/b/g/n/ac-W2 only FortiWifi Model
USB Ports	1
Console (RJ45)	1
Internal Storage	-	1 x 128 GB SSD
System Performance - Enterprise Traffic Mix
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	700 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	10/10/6 Gbps
Firewall Latency (64 byte UDP packets)	4 μs
Firewall Throughput (Packets Per Second)	9 Mpps
Concurrent Sessions (TCP)	700,000
New Sessions/Second (TCP)	35,000
Firewall Policies	5,000
IPsec VPN Throughput (512 byte packets)	6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	500
SSL-VPN Throughput	900 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	200
SSL Inspection Throughput	750 Mbps
SSL Inspection CPS (IPS, avg. HTTPS)	400
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	55,000
Application Control Throughput	1.8 Gbps
CAPWAP Throughput (HTTP 64K)	15 Gbps
NGFW Throughput	250 Mbps
Threat Protection Throughput	180 Mbps
CAPWAP Throughput	1.5 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	16
Maximum Number of FortiAPs (Total / Tunnel Mode)	30 / 10
Maximum Number of FortiTokens	500
Maximum Number of Registered FortiClients	200
High Availability Configurations	Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (inches)	1.5 x 8.5 x 6.3
Height x Width x Length (mm)	38 x 216 x 160
Weight	1.9 lbs (0.9 kg)
Form Factor	Desktop
Operating Environment and Certifications
Power Required	100-240V AC, 50-60 Hz (External DC Power Adapter, 12 VDC)
Maximum Current	115V AC / 0.2A, 230V AC / 0.1A
Power Consumption (Average / Maximum)	17.0 W / 18.5 W	17.2 W / 18.7 W
Heat Dissipation	63.1 BTU/hr	63.8 BTU/hr
Operating Temperature	32-104°F (0-40°C)
Storage Temperature	-31-158°F (-35-70°C)
Humidity	10-90% non-condensing
Noise Level	Fanless 0 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN

SKU	124566
Barcode #	842382199855
Shipping Weight	1.8700kg
Shipping Width	0.210m
Shipping Height	0.120m
Shipping Length	0.290m
