TP-Link ES205GP Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
SKU: 126251
TP-Link ES205GP Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
SKU: 126251
$79.00
30
In Stock at store/warehouse
- 5× 10/100/1000Mbps RJ45 ports (4× 802.3at/af-compliant PoE+)
- 65W Power Budget, with up to 30W for each PoE port*
- Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
- Centralised Cloud Management via the web or the Omada app†
- Up to 250m PoE**, QoS△, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
- Automatic Loop Prevention, VLAN, and IGMP Snooping
- Fanless design for silent operation
- Durable metal casing and desktop/wall mounting design
(126251)
| HARDWARE FEATURES | |
| Interface | • 5× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3at PoE+ and 802.3af PoE) |
| • Auto-Negotiation/Auto MDI/MDIX | |
| Fan Quantity | Fanless |
| Installation | • Desktop |
| • Wall Mount | |
| Physical Security Lock | √ |
| Power Supply | DC Power Adapter (Output: 53.5 VDC/ 1.31 A) |
| PoE Ports (RJ45) | • Standard: 802.3af PoE and 802.3at PoE+ compliant |
| • PoE Ports: 4 ports | |
| • PoE Budget: 65 W available for all PoE+ ports, 30W max per port | |
| • PoE Auto Recovery‡ | |
| • Up to 250m PoE transmission distance** | |
| Dimensions ( W x D x H ) | 3.9×3.9×1.0 in (100×98×25 mm) |
|
PERFORMANCE
|
|
| Switching Capacity | 10 Gbps |
| Packet Forwarding Rate | 7.4 Mpps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4 Mbit |
| Jumbo Frame | 15 KB |
|
SOFTWARE FEATURES
|
|
| Quality of Service | • Port-based/802.1p/DSCP QoS |
| • 8 Priority Queues | |
| • Priority Schedule Mode | |
| - WRR (Weighted Round Robin) | |
| • Queue Weight Config | |
| • Bandwidth Control | |
| - Port-Based Rating Limit | |
| • Storm Control | |
| - Multiple Control Modes (kbps/pps) | |
| - Broadcast/Multicast/Unknown-Unicast Control△ | |
| L2 Features | • Static Link Aggregation |
| • Loop Prevention / Loopback Detection | |
| • Flow Control | |
| - 802.3x Flow Control | |
| • Mirroring | |
| - Port Mirroring | |
| - One-to-One | |
| - Many-to-One | |
| - Ingress/Egress/Both | |
| • Port Statistics | |
| - Port Mirror Status | |
| - Traffic Statistics | |
| • 802.1ab LLDP | |
| L2 Multicast | • IGMP Snooping |
| - IGMP v1/v2/v3 Snooping | |
| - Fast Leave | |
| VLAN | • MTU VLAN |
| • Port-Based VLAN | |
| • 802.1Q Tag VLAN | |
| - Max 32 VLAN Groups | |
| - 4K VID | |
| Transmission Method | Store-And-Forward |
|
MANAGEMENT
|
|
| Omada App | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller |
| • Omada Hardware Controller | |
| • Omada Software Controller | |
| Cloud Access | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller |
| Management Features | • Web-based GUI |
| • DHCP Client | |
| • Cable Diagnostics | |
| • Automatic Device Discovery† | |
| • Batch Configuration† | |
| • Batch Firmware Upgrading† | |
| • Unified Configuration† | |
|
OTHERS
|
|
| Certification | FCC, CE, RoHS |
| Package Contents | • ES205GP |
| • Power Adapter | |
| • Installation Guide | |
| • Rubber Feet | |
| Environment | • Operating Temperature: 0℃~40℃ (32℉~104℉) |
| • Storage Temperature: -40℃~70℃ (-40℉~158℉) | |
| • Operating Humidity: 10%~90% non-condensing | |
| • Storage Humidity: 5%~90% non-condensing | |
| SKU | 126251 |
| Model # | ES205GP |
| Barcode # | 8885020620931 |
| Brand | TP-LINK |
| Shipping Weight | 0.5900kg |
| Shipping Width | 0.130m |
| Shipping Height | 0.120m |
| Shipping Length | 0.190m |
