Adptv D-pad Button Comm EN/XT/JA/KO APOC Commercial Black

SKU: 126164

The Adaptive D-pad Button Communication Kit offers intuitive four-directional control for users with limited fine-motor dexterity. Designed to connect to the Surface Adaptive Hub (sold separately) via a standard 3.5 mm jack, its low-force silicone D-pad lets users navigate up, down, left or right, while an optional center press can be mapped as a “select” action. The module arrives in matte-black ABS with peel-and-stick language overlays for English, Traditional Chinese (XT), Japanese (JA) and Korean (KO), tailored for Asia Pacific commercial deployments. Mount it where it’s most accessible using the included snap-on clip or 3M™ adhesive pad. Bus-powered through the hub, it requires no batteries and is configured via Microsoft’s Adaptive Tools on Windows 10+ and Windows 11 Pro.

(126164)

Specification Detail
Product Name Surface Adaptive D-pad Button Communication Kit
Part Number ADPTV D-pad Button Comm EN/XT/JA/KO APOC Commercial Black
Interface 3.5 mm mono jack (connects to Adaptive Hub Communication Kit)
Control Type Low-force silicone 4-direction D-pad + optional center press
Compatibility Windows 10 (1809+) / Windows 11 Pro via Adaptive Hub and Microsoft Adaptive Tools
Power Source Bus-powered through Adaptive Hub (no batteries required)
Materials ABS plastic housing; soft-touch silicone directional pad
Mounting Options Snap-on clip; 3M™ adhesive pad
Language Overlays English (EN), Traditional Chinese (XT), Japanese (JA), Korean (KO) peel-and-stick legends
Dimensions (W × D × H) 44 × 44 × 16 mm
Weight Approx. 25 g
Operating Temperature 0 °C to 40 °C
Storage Temperature –20 °C to 60 °C
Warranty 1-Year Microsoft hardware warranty
SKU 126164
Shipping Width 0.100m
Shipping Height 0.100m
Shipping Length 0.100m
