TP-Link SM5110LSA-10 Omada 10GBase-BX WDM Bi-Directional SFP+ LC Module

SKU: 125972

  • Supports WDM Bi-Directional technology, using a single strand of fiber, cost saving
  • Single mode SFP+ LC Transceiver
  • Hot-Pluggable with maximum flexibility
  • Supports Digital Diagnostic Monitoring (DDM)
  • Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+)
  • Compatible with switches with 10G ports like SG3428X and SG3452X

What This Product Does

The SM5110LSA-10 is designed to extend transmission distance up to 10km with a maximum rate of 10Gbps. It is a single-mode SFP+ transceiver that supports bi-directional data transmission, which is cost-saving.



*Note: Use SM5110LSA-10 & SM5110LSB-10 together for fast and reliable connectivity.

(125972)

PACKAGE CONTENTS
Package Contents • SM5110LSA-10
• Installation Guide

HARDWARE FEATURES
DDM Yes
Hot Swappable Yes
Dimensions ( W x D x H ) 2.24*0.55*0.47 in (57*14*12.0 mm)

TRANSCEIVER
Standards and Protocols • IEEE 802.3ae
• SFF 8431, SFF 8432, SFF-8472
Wavelength •TX: 1330nm
•RX: 1270nm
Power Supply 3.3V
Fiber Type 9μm/125μm Single-Mode
Max. Cable Length 10km
Data Rate 10.3125 Gbps
Connector LC/UPC
Regulatory Compliance CE, FCC, RoHS
Environment • Operating Temperature: 0°C to 70°C (32–158 ℉)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Operating Humidity: 10% to 90% RH non-condensing
• Storage Humidity: 5% to 90% RH non-condensing
SKU 125972
Model # SM5110LSA-10
Shipping Weight 1.0000kg
Shipping Width 0.200m
Shipping Height 0.100m
Shipping Length 0.200m

Be The First To Review This Product!

Help other OnLine Centre Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

  • Supports WDM Bi-Directional technology, using a single strand of fiber, cost saving
  • Single mode SFP+ LC Transceiver
  • Hot-Pluggable with maximum flexibility
  • Supports Digital Diagnostic Monitoring (DDM)
  • Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+)
  • Compatible with switches with 10G ports like SG3428X and SG3452X

What This Product Does

The SM5110LSA-10 is designed to extend transmission distance up to 10km with a maximum rate of 10Gbps. It is a single-mode SFP+ transceiver that supports bi-directional data transmission, which is cost-saving.



*Note: Use SM5110LSA-10 & SM5110LSB-10 together for fast and reliable connectivity.

PACKAGE CONTENTS
Package Contents • SM5110LSA-10
• Installation Guide

HARDWARE FEATURES
DDM Yes
Hot Swappable Yes
Dimensions ( W x D x H ) 2.24*0.55*0.47 in (57*14*12.0 mm)

TRANSCEIVER
Standards and Protocols • IEEE 802.3ae
• SFF 8431, SFF 8432, SFF-8472
Wavelength •TX: 1330nm
•RX: 1270nm
Power Supply 3.3V
Fiber Type 9μm/125μm Single-Mode
Max. Cable Length 10km
Data Rate 10.3125 Gbps
Connector LC/UPC
Regulatory Compliance CE, FCC, RoHS
Environment • Operating Temperature: 0°C to 70°C (32–158 ℉)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Operating Humidity: 10% to 90% RH non-condensing
• Storage Humidity: 5% to 90% RH non-condensing
SKU 125972
Model # SM5110LSA-10
