QNAP 8+4 BAY NAS (NO DISK) XEON 6-CORE 3.3GHz, 16GB, 10GbE (2), 2.5GbE(4), TWR, 3YR WTY

SKU: 125838

The high-capacity TVS-h1288X features a powerful Intel® Xeon® W processor and allows for installing two QNAP QXP-T32P Thunderbolt™ 3 PCIe expansion cards (sold separately) to attain four Thunderbolt™ 3 ports, making it a perfect match for Thunderbolt™-equipped Mac® and Windows® users for high-speed media collaboration. The built-in 10GbE and 2.5GbE connectivity supports Port Trunking and failover to further satisfy bandwidth and reliability demanding business applications. Running the ZFS-based QuTS hero operating system, the TVS-h1288X supports block-level inline data deduplication and compression, near-limitless snapshots, real-time SnapSync, and read/write cache technologies, helping your business achieve reliable service-level agreement performance, from creative workflows to file server, virtualization server, and efficient file backup and recovery applications.

  • Attain quad-port Thunderbolt™ 3 connectivity by installing two QXP-T32P expansion cards in the PCIe Gen 3 x4 slots.
    Note: QXP-T32P expansion cards are sold separately

  • Two 10GBASE-T and four 2.5GbE LAN ports accelerate virtualization, intensive file access, large backup/restoration tasks, and media transfer.

  • PCIe slots allow for installing 5/10/25/40GbE adapters, QM2 cards, or graphics cards to increase application performance.

  • 4K media playback and real-time transcoding; directly output videos to an HDMI display (up to 4K @30Hz).

  • Supports virtual machines and containerized apps, centralized storage, backup, sharing, disaster recovery, and storage expansion.

  • Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud.

Available Models

  • TVS-h1288X-W1250-16G

  1. TVS-h1288X-W1250-16G

    Intel® Xeon® W-1250 6-core 3.3 GHz processor (Bust up to 4.7 GHz), 16 GB DDR4 ECC memory (2 x 8 GB)

Six cores up to 4.7 GHz with up to 128 GB DDR4 ECC memory

Intel® Xeon® W processors are designed for a wide range of creative professionals. Powered by an Intel® Xeon® W-1250 6 cores/12 threads 3.3 GHz processor (Burst up to 4.7 GHz), the TVS-h1288X has enormous processing power to drive virtual machine performance. The integrated Intel® AES-NI encryption engine boosts encryption performance while also maintaining the security of NAS data. With dual-channel modules and 4 Long-DIMM slots, the TVS-h1288X’s DDR4 ECC memory can be upgraded up to 128 GB for memory-intensive and complex multitasking workloads.

Windows Sequential File Transfer (4 x 10 GbE, 512K)

Upload

3651 MB/s

Download

4646 MB/s

Windows Random File Transfer (4 x 10 GbE, 4K)

Upload

187701 IOPS

Download

387204 IOPS

Tested in QNAP Labs. Figures may vary by environment.

NAS: TVS-h1288X (25GbE CX4 x2 running at 10GbE x4 port)
OS: QuTS hero h4.5.0
Volume Type: 8 x Seagate ST6000VN0033 6TB HDD (RAID 5) + 2 x Samsung 960 PRO 2TB SSD cache
Client PC: Windows Server 2016, Intel Core i7-7700 3.6 GHz, 32 GB RAM
IOmeter: 4GB, 30-sec ramp up time, 3-min random run time, 8 workers, 16-outstanding

Virtualization Certifications Supported by TVS-h1288X



Streamline video editing and 4K workflows with Thunderbolt™ 3 connectivity

You can install two QXP-T32P Thunderbolt™ 3 expansion cards (sold separately) to the PCIe Gen 3 x4 slots of the TVS-h1288X and transform it into a Thunderbolt™ 3 NAS with quad-port Thunderbolt™ 3 connectivity. Up to four Thunderbolt™-equipped workstations can be connected to the TVS-h1288X to achieve greater teamwork efficiency in 4K workflows, file storage, backup, and sharing. An SLC/MLC SSD RAID 5 configuration is recommended for the highest possible performance and the best storage allocation for your NAS.

Note: If you connect a Thunderbolt™ 4 computer to a Thunderbolt™ 3 NAS, you must use a Thunderbolt™ 4 certificated cable or a passive Thunderbolt™ 3 cable that is shorter than 0.8 meters.



Thunderbolt™ 3 + 10Gb Ethernet: perfect for studios and post-production houses

The TVS-h1288X can simultaneously run general Ethernet services with the built-in 10GBASE-T LAN card in addition to the Thunderbolt™ 3 network, completely independently and with no bandwidth interference. The media resources in the TVS-h1288X can be easily accessed by Thunderbolt™ and Ethernet workstations for different concurrent tasks with increased productivity.

  • Adobe® Premiere Pro® and Final Cut Pro® collaboration

    Final Cut Pro® and Adobe® Premiere Pro® users can centrally store and share the media files in the TVS-h1288X via SMB protocol for greater efficiency.

  • Quick access with Qfinder Pro

    Qfinder Pro allows you to quickly find and easily access QNAP NAS that are located on the same LAN. You can mount the TVS-h1288X through Qfinder Pro for direct access to specific shared folders.

  • Blazing-fast 10GbE/5GbE connectivity for Mac®/Windows®

    Add high-speed connectivity to computers by using the Thunderbolt 3 to 10GbE adapter or USB 3.2 Gen 1 to 5GbE adapter. Servers and desktop computers can install PCIe network expansion cards that support 10G/5G/2.5G/1G/100M Multi-Gig. QNAP 10GbE switches allow for high-speed collaboration in device-dense environments.

Adobe® Premiere Pro® and Final Cut Pro® collaborationQuick access with Qfinder ProBlazing-fast 10GbE/5GbE connectivity for Mac®/Windows®
  •

(125838)

SKU 125838
Shipping Width 0.100m
Shipping Height 0.100m
Shipping Length 0.100m
