QNAP 12+4 BAY NAS (NO DISK) ATOM 8-CORE 2.8GHz, 8GB, 2.5GbE(2), M.2(2), 3YR WTY

SKU: 125833

QNAP 12+4 BAY NAS (NO DISK)  ATOM 8-CORE 2.8GHz, 8GB, 2.5GbE(2), M.2(2), 3YR WTY



QNAP TS-1655-8G,16-bay NAS Intel ® Atom® C5125 8-core processor, 2.8GHz, 8 GB UDIMM DDR4 (1 x 8 GB)

Balance performance and cost with hybrid storage. Designed for diversified business IT environments, the high-capacity TS-1655 has twelve 3.5-inch SATA drive bays (for HDDs) and four 2.5-inch SATA drive bays (for SSDs) with 2.5GbE high-speed connectivity. Fueled by an immense 8-core Intel Processor, the TS-1655 presents a secure, scalable, and complete business-ready storage solution for cross-team file sharing, collaboration, backup & disaster recovery, virtualization, and intensive data transmission. The TS-1655 will be available and supported by QNAP for an extended period (up to 2027), ideal for businesses requiring matching NAS models deployed in multiple locations.

intel-atom2.5GbEm.2-nvme-ssdpcie

  • Dual 2.5GbE connectivity

    High-speed 2.5GbE accelerates intensive file access, large backup/restoration tasks, virtualization, and multimedia transfer.

  • SSD caching and AI acceleration

    Two M.2 NVMe PCIe Gen 3 slots allow implementing SSD cache acceleration, SSD storage pool, or a Coral M.2 accelerator for faster image recognition.

  • Flexible PCIe expansion

    Three PCIe slots allow for installing 5/10/25GbE adapters, Fibre Channel cards, or QM2 cards to increase application performance.

  • Virtual machines and containers

    Host virtual machines and containerized apps on one device to optimize resource utilization and IT budgeting. Supports SR-IOV.

  • Hybrid cloud

    Realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency cloud data access.

  • Storage scalability

    Satisfy ever-growing storage needs by connecting flexible and economical QNAP expansion enclosures.

Available Model

  • TS-1655-8G

    Intel ® Atom® C5125 8-core processor, 2.8GHz, 8 GB UDIMM DDR4 (1 x 8 GB)

Eight cores up to 2.8 GHz, Intel® QuickAssist Technology, and up to 128 GB memory

The TS-1655 adopts the Intel® Atom® C5125 8-core 2.8 GHz processor that supports Intel® QuickAssist Technology (QAT), offloading computationally-intensive compression and improving IPsec/SSL cryptography performance. The TS-1655 comes with four UDIMM DDR4 slots (8 GB preinstalled) that can be upgraded to 128 GB for higher workloads. Error-Correcting Code memory is also supported to deliver server-grade performance and reliability for rugged enterprise IT environments as a cost-efficient NAS solution.

Transmission efficiency

Windows File Transfer (2x 2.5GbE)
10 Gigabytes file transfer

Read

525 MB/s

Write

582 MB/s

SMB Sequential Throughput (2x 10GbE)

Read

2362 MB/s

Write

1936 MB/s

SMB Sequential Throughput (2x 25GbE)

Read

3499 MB/s

Write

2465 MB/s

 Tested in QNAP Labs. Figures may vary by environment.

Test Environment:
2x10GbE:
NAS : TS-1655 , Intel Atom(R) C5125 processor, 2800 MHz (8C8T) , 8GB , Samsung 860 EVO 1TB x16 ,RAID 5, 10GbE NIC (QXG-10G2TB)
Client PC : Intel i7-6700 3.4GHz , DDR4 64GB (16GB x4) , Windows Server 2016
2x 25GbE:
NAS : TS-1655 , Intel Atom(R) C5125 processor, 2800 MHz (8C8T) , 8GB , Samsung 860 EVO 1TB x16 ,RAID 5, 25GbE NIC (QXG-25G2SF-CX6)
Client PC : AMD EPYC 7302P 3.0GHz , DDR4 128GB (32GB x4) , Windows Server 2019

Virtualization Certifications Supported by TS-1655

Check QNAP NAS with Support for Virtualization application

Affordable, faster 2.5GbE meets today’s high-bandwidth demands

Featuring two native 2.5GbE RJ45 LAN ports (backwards compatible with 1G/100M), the TS-1655 allows you to upgrade network speeds from 1 Gigabit to 2.5 Gigabit using existing CAT5e cables. Port Trunking and failover support further satisfies bandwidth and reliability demanding applications including virtualization, large file transfers, high-speed backup/restoration, and real-time applications. QNAP also offers numerous managed/unmanaged 2.5GbE/10GbE switches, assisting organizations in implementing high-speed, secure, and scalable network environments without going over budget.

Learn More: QNAP 2.5GbE solutionsQNAP 10GbE solutionsBudget-friendly QSW series switches

M.2 slots for SSD caching and accelerated AI-powered image recognition

The TS-1655 is equipped with two M.2 PCIe Gen 3 slots that allow for installing NVMe PCIe Gen 3 SSDs with 2280 form factors or Edge TPU (sold separately) to boost NAS performance.

  • SSD caching

    Configure SSD caching with M.2 SSDs to obtain optimal I/O and reduced latency without occupying any 3.5-inch drive bays. Learn more: SSD cache accelerationQNAP SSD Technology

  • Auto Tiering

    Qtier™ technology empowers the TS-1655 with auto tiering to continuously optimize storage efficiency across all installed storage devices. Learn more: Qtier auto-tiering

  • Faster image recognition with Edge TPU

    Coral M.2 Accelerator with Edge TPU provides an affordable solution to leverage AI acceleration for faster image recognition in your NAS applications. (Purchase from Coral website)

SSD caching

Auto Tiering

Faster image recognition with Edge TPU

Abundant I/O capabilities with PCIe expansion

The TS-1655 has three PCIe Gen 3 x4 slots that allow for installing various expansion cards for expanding application potential.



(125833)

SKU 125833
Shipping Width 0.100m
Shipping Height 0.100m
Shipping Length 0.100m
