QNAP 4-BAY NAS (NO DISK), OCTEON QC 2.2GHz, 4GB, 2.5GbE(2), 10GbE SFP+(2),M.2(2), 1U, 3YR

SKU: 125809

The compact and feature-rich TS-435XeU provides a professional-grade quad-core NAS solution in short depth rackmount form factor. The native 10GbE SFP+ and 2.5GbE connectivity alongside M.2 NVMe SSD slots that enable cache acceleration allows businesses to efficiently tackle everyday tasks like file backup/restore and to boost team collaboration with higher productivity. The space-efficient short depth design makes the TS-435XeU easy to install in small media cabinets or places with a lot of cabling. Supporting abundant business applications (including file sharing and sync, snapshot protection, containerization, cloud storage gateways, and video streaming), expandable storage capacity, and install-on-demand apps, the TS-435XeU is an ideal cost-effective entry-level rackmount NAS.

marvell_2

  • 2 x 10GbE SFP+ ports

    Dual-port 10GbE SFP+ connectivity accelerates intensive file access, large backup/restoration tasks, and media transfer.

  • 2 x 2.5GbE ports

    Up to 5 Gbps transfer speeds can be made by setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports.

  • SSD cache acceleration

    Dual M.2 PCIe Gen 3 NVMe SSD slots enable cache acceleration or SSD storage pools for improved performance.

  • Containerized applications

    Host multiple containerized apps to run a wide range of applications and services.

  • Surveillance system

    Build a surveillance system with lower TCO and higher scalability with the subscription-based QVR Elite smart surveillance solution.

  • Flexible storage expansion

    Scale your storage capacity to fit growing data needs by connecting QNAP’s expansion units.

(125809)

CPU Marvell OCTEON TX2™ CN9130 / CN9131 ARMv8 Cortex-A72 4-core 2.2GHz processor
CPU Architecture 64-bit ARM
Floating Point Unit
Encryption Engine
System Memory 4 GB SODIMM DDR4 (1 x 4GB)
Maximum Memory 32 GB (1 x 32 GB)
Memory Slot 1 x SODIMM DDR4
Flash Memory 4GB (Dual boot OS protection)
Drive Bay 4 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
M.2 Slot 2 x M.2 2280 PCIe Gen 3 x1 slots
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2 (2.5G/1G/100M)
10 Gigabit Ethernet Port 2 x 10GbE SFP+
Wake on LAN (WOL)
Jumbo Frame
USB 2.0 port 2
USB 3.2 Gen 1 port 2
Form Factor 1U Rackmount
LED Indicators HDD 1-4, Status, LAN, USB, M.2 SSD 1-2
Buttons Power, Reset
Dimensions (HxWxD) 43.3 × 430 × 292.12 mm

Excludes ear hook and the protruding part of the Power Supply Unit.

Weight (Net) 4.17 kg
Operating Temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 100W PSU, 100-240V
Power Consumption: HDD Sleep Mode 17.367 W
Power Consumption: Operating Mode, Typical 30.878 W
Fan 3 x 40mm, 12VDC
System Warning Buzzer
Kensington Security Slot
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 1500
SKU 125809
Shipping Width 0.100m
Shipping Height 0.100m
Shipping Length 0.100m
