TP-Link VIGI NVR1004H VIGI 4 Channel Network Video Recorder
SKU: 125195
TP-Link VIGI NVR1004H VIGI 4 Channel Network Video Recorder
SKU: 125195
$109.00
18
In Stock at store/warehouse
- 4-Channel Live View and 4K HDMI Video Output
- 2-ch @ 8MP/ 4-ch @ 4MP Decoding Capability
- 4-Channel Synchronous Playback†
- 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth
- 1 SATA Interface (up to 10 TB) *
- H.265+ Compression Technology
- HDMI and VGA Simultaneous Output
- Remote Monitoring
(125195)
| VIDEO AND AUDIO | |
| IP Video Input | 4-Channel |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| Video Output Mode | HDMI/VGA Simultaneous Output |
| Multi-View Display | 1-Apr |
|
DECODING
|
|
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Record Resolution | 8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous Playback | 4-Channel |
| Capability | 2-ch @ 8MP, 4-ch @ 4MP |
|
RECORD MANAGEMENT
|
|
| Record Mode | • Manual Recording |
| • Scheduling Recording | |
| • Motion Detection Recording | |
| Playback Mode | • Instant Playback |
| • Regular Playback | |
| • Tag Playback | |
| • Event Playback | |
| Backup Mode | • Regular Backup |
| • Video Clip Backup | |
| Playback Function | • Play |
| • Pause | |
| • Stop | |
| • Fast Forward | |
| • Fast Backward | |
| • Play By Frame | |
| • Full Screen | |
| • Video Clip | |
| • Export Clip | |
| • Digital Zoom | |
| • Lock Recording | |
| • Audio On/Off | |
|
NETWORK
|
|
| Protocol | UPnP (Plug and Play), NTP (Network Timing) |
| Mobile Phone Access | Android, iOS |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF, CGI |
|
EXTERNAL INTERFACE
|
|
| Network Interface | 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 2× USB 2.0 |
| Audio Interface | 1, Audio In; 1, Audio Out |
| Alarm In/Out | N/A |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | N/A |
| HDMI | 1 |
| VGA | 1 |
|
HARD DISK
|
|
| SATA | 1 SATA Interface |
| Capacity | Up to 10 TB Capacity for Each HDD* |
|
ALARM
|
|
| General Alarm | • Motion Detection |
| • Video Tampering | |
| • Line-Crossing Detection | |
| • Intrusion Detection | |
| • Region Entering Detection | |
| • Region Exiting Detection | |
| • Object Abandoned/Removal Detection | |
| • Vehicle Detection | |
| • Human Detection | |
| • Smart Frame | |
| Anomaly Alarm | • Video Loss |
| • Offline and IP Conflict | |
| • Disk Exception | |
| • Login Exception | |
| Alarm Linkage | • Recording |
| • White Light Alarm | |
| • Buzzer | |
| • Log | |
| • Audible Alarm | |
|
GENERAL
|
|
| Storage Temperature | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Package Contents | • VIGI Network Video Recorder |
| • Power Adapter | |
| • HDD Screws | |
| • Mouse | |
| • Rubber Feet | |
| • Quick Installation Guide | |
| Working Temperature | • NVR: -10–55 °C |
| • Power Adapter: 0–40 °C | |
| Working Humidity | 10%~90% RH Non-Condensing |
| Dimensions( W X D X H ) | 246.2 × 148.2 × 45 mm |
| External Power Supply | DC 12V/1.5A |
| Net Weight | 0.59 kg |
| Gross Weight | 0.95 kg |
| Power Consumption | 4.25 W (Without Disk) |
| Certifications | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
| SKU | 125195 |
| Model # | VIGI NVR1004H |
| Barcode # | 8885020620412 |
| Brand | TP-LINK |
| Shipping Weight | 1.0600kg |
| Shipping Width | 0.280m |
| Shipping Height | 0.060m |
| Shipping Length | 0.300m |
