SKU: 122530
SKU: 122530
(122530)
| HARDWARE FEATURES | |
| Interface | • 9× 10/100/1000 Mbps RJ45 Ports |
| • 1× 1000 Mbps Combo SFP/RJ45 Port | |
| • AUTO Negotiation | |
| • AUTO MDI/MDIX | |
| Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| • EIA/TIA-568 100Ω STP (maximum 100m) | |
| • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) | |
| • EIA/TIA-568 100Ω STP (maximum 100m) | |
| Fan Quantity | Fanless |
| Physical Security Lock | Yes |
| External Power Supply | External Power Adapter (Output: 53.5VDC / 2.43A) |
| Packet Forwarding Rate | 14.88 Mpps |
| PoE Ports (RJ45) | • Standard: 802.3 af/at compliant |
| • PoE Ports: Ports 1–8 | |
| • Power Supply: 123 W | |
| Mac Address Table | 4K |
| Jumbo Frame | 16 KB |
| Switching Capacity | 20 Gbps |
| Dimensions ( W x D x H ) | 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
| Max Power Consumption | • 7.93 W (220V / 50Hz with no PD connected) |
| • 141.40 W (220V / 50Hz with 123 W PD connected) | |
| Max Heat Dissipation | • 27.04 BTU/h (220V / 50Hz with no PD connected) |
| • 482.17 BTU/h (220V / 50Hz with 123 W PD connected) | |
| SOFTWARE FEATURES | |
| Transmission Method | Store-And-Forward |
| Advanced Functions | • Compatible With IEEE 802.3af/at Compliant PDs |
| • Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission) | |
| • Priority Mode Button (Ports 1–2) | |
| • Isolation Mode Button (Ports 1–4 / 5-8) | |
| • PoE Auto Recovery (Ports 1-8) | |
| • Mac Address Auto-Learning and Auto-Aging | |
| • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode | |
| OTHERS | |
| Certification | FCC, CE, RoHS |
| Package Contents | • TL-SG1210MP |
| • Power Adapter | |
| • Installation Guide | |
| Environment | • Operating Temperature: 0–40 ℃ (32–104 ℉) |
| • Storage Temperature: -40–70 ℃ (-40–158 ℉) | |
| • Operating Humidity: 10–90% RH non-condensing | |
| • Storage Humidity: 5–90% RH non-condensing | |
| SKU | 122530 |
| Model # | TL-SG1210MP |
| Barcode # | 6935364052683 |
| Brand | TP-LINK |
| Shipping Weight | 1.6000kg |
| Shipping Width | 0.240m |
| Shipping Height | 0.070m |
| Shipping Length | 0.320m |
