TP-Link EAP683 UR AX6000 Ceiling Mount Wi-Fi 6 Access Point
SKU: 125414
TP-Link EAP683 UR AX6000 Ceiling Mount Wi-Fi 6 Access Point
SKU: 125414
$269.00
100
In Stock at store/warehouse
- Up to 5952 Mbps Wi-Fi 6 Speeds: 1148 Mbps on 2.4 GHz + 4804 Mbps on 5 GHz†
- Ultra-range wireless coverage by 4×4 MIMO dual-band internal antennas with high transmission power.
- Supports Wi-Fi 6 technologies, such as HE160, 1024-QAM, etc.‡
- Integrates with the Omada SDN platform for centralised management.
- Advanced Features: Omada Mesh, Seamless Roaming, and more.§
- PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter not included).
(125414)
| HARDWARE FEATURES | |
| Interface | 1× 2.5 Gigabit PoE+ Port |
| Button | Reset |
| Power Supply | • 802.3at PoE |
| • 12 V / 2 A DC | |
| Note：Power adapter is not included. | |
| Power Consumption | • EU: 20.43W |
| • US: 23.69W | |
| Dimensions ( W x D x H ) | 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm) |
| Antenna Type | Internal Omni |
| • 2.4 GHz: 4× 4 dBi | |
| • 5 GHz: 4× 5 dBi | |
| Bluetooth | Yes |
| Mounting | Ceiling /Wall Mounting (Kits included) |
|
WIRELESS FEATURES
|
|
| Coverage | 185㎡(2000ft²)*** |
| Concurrent Clients | 510+** |
| Wireless Standards | IEEE 802.11ax/ac/n/g/b/a |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | • 5 GHz: Up to 4804 Mbps |
| • 2.4 GHz: Up to 1148 Mbps | |
| Wireless Functions | • 1024-QAM |
| • 4× Longer OFDM Symbol | |
| • OFDMA | |
| • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) | |
| • Enable/Disable Wireless Radio | |
| • Automatic Channel Assignment | |
| • Transmit Power Control (Adjust Transmit Power on dBm) | |
| • QoS(WMM) | |
| • MU-MIMO | |
| • HE160 (160 MHz Bandwidth)‡ | |
| • Seamless Roaming § | |
| • Omada Mesh§ | |
| • Band Steering | |
| • Load Balance | |
| • Airtime Fairness | |
| • Beamforming | |
| • Rate Limit | |
| • Reboot Schedule | |
| • Wireless Schedule | |
| • Wireless Statistics based on SSID/AP/Client | |
| Wireless Security | • Captive Portal Authentication§ |
| • Access Control | |
| • Wireless Mac Address Filtering | |
| • Wireless Isolation Between Clients | |
| • SSID to VLAN Mapping | |
| • Rogue AP Detection | |
| • 802.1X Support | |
| • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise | |
| Transmission Power | • CE: <20 dBm(2.4 GHz, EIRP) |
| <23 dBm(5 GHz, band1 & band2, EIRP) | |
| <28 dBm(5 GHz, band3, EIRP) | |
| • FCC: <26 dBm (2.4 GHz) | |
| <26 dBm (5 GHz) | |
|
MANAGEMENT
|
|
| Omada App | Yes |
| Centralized Management | • Omada Hardware Controller (OC300) |
| • Omada Hardware Controller (OC200) | |
| • Omada Software Controller | |
| • Omada Cloud-Based Controller | |
| Cloud Access | Yes. Require the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| SSH | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Require the use of Omada Cloud-Based Controller. |
|
OTHERS
|
|
| Certification | CE,FCC,RoHS |
| Package Contents | • EAP683 UR |
| • Ceiling/Wall Mounting Kits | |
| • Installation Guide | |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | • Operating Temperature: 0–40 ℃ (32–104 ℉) |
| • Storage Temperature: -40–70 ℃ (-40–158 ℉) | |
| • Operating Humidity: 10–90% RH non-condensing | |
| • Storage Humidity: 5–90% RH non-condensing | |
| SKU | 125414 |
| Model # | EAP683 UR |
| Barcode # | 8885020621938 |
| Brand | TP-LINK |
| Shipping Weight | 0.6100kg |
| Shipping Width | 0.260m |
| Shipping Height | 0.090m |
| Shipping Length | 0.280m |
